300mm Manual Roller Rolling Press

Detail Information

Place of Origin	China	Brand Name	GERUISI
Applicable Industries:	Battery Electrode Roll Press	Width:	300mm
Tablet Thickness:	0~2mm	Roller Cylindricity::	≤ ± 2um
Highlight	Cylindrical Cell Assembly Machine Rolling Press, 300mm Cylindrical Cell Assembly Machine, 300mm lithium ion battery manufacturing machine

Product Description

The manual vertical roller counter machine is mainly suitable for manual rolling of battery materials, small amounts of precious metal materials such as gold and silver, and nonferrous materials such as copper and aluminum in the laboratory.

Especially suitable for thinning and increasing density of lithium battery plates, which are clean energy materials. Gear transmission is adopted to achieve roller pressing, with adjustable rolling thickness and convenient use.

Specification

Method	Manual
Roller diameter	2~Φ96mm
Surface hardness of roller	>HRC60
Roller finish	>0.4
Tablet thickness	0~2mm
Tablet width	0~300mm
Roll placement	Vertical placement
Overall dimensions	L600mm * W300mm * H330mm;
Overall dimensions	70Kg
