| Place of Origin | China | Applicable Industries: | Bettery Electrode Roll Press |
| Rolling Force: | Max.25T | Rolling Speed: | Max.6m/min |
| Roll Surface Width: | 300 Mm |
|
Roller diameter
|
2- Φ96mm
|
|
Roller cylindricity
|
≤±2um
|
|
Roller hardness
|
HRC62
|
|
Roller finish
|
>0.4
|
|
Rolling thickness
|
0~ 2mm gap adjustable
|
|
Tablet width
|
0 ~ 100mm
|
|
Roll placement
|
Horizontal placement
|
|
Operation mode
|
electric
|
|
Voltage and frequency
|
AC220V/50Hz
|
|
power
|
120W
|
|
Feed speed
|
0 * 40mm/s
|
|
Other advantages
|
Pressing thickness, speed adjustable
|
|
Overall dimensions
|
L500mm*W360mm*H620mm
|
|
Weight
|
70KG |
