| Brand Name | GERUISI | Model Number | GRS-XQM1 |
| Output (kg/h): | 10 - 20 Kg/h | Feeding Size (mm): | 0 - 10 Mm |
| Output Size (mesh): | 0 - 100 Mesh | Power (kW): | 0.5 |
| Range Of Spindle Speed(r.p.m): | 50 - 400 R.p.m | Material: | SUS304 |
| Type: | Ball Mill | Machinery Test Report: | Provided |
| Air Press: | 2MPa |
|
Grinder specifications
|
250mL*4
|
|
Grinding tank material
|
Stainless steel, nylon, corundum ceramics, zirconia, etc
|
|
Grinding material
|
Stainless steel, agate, nylon, corundum ceramics, zirconia, etc
|
|
Maximum charge per can
|
Materials and grinding media shall not exceed two-thirds of the volume
|
|
Feed particle size
|
Crispy materials less than 10mm, others less than 3mm
|
|
Discharging particle size
|
Up to 0.1 micron minimum
|
|
rotate speed
|
Revolution maximum 0-400r/min, Autorotation: 0-800 r/min
|
|
Speed ratio
|
(Revolution: Autorotation) 1:2
|
|
Speed adjust method
|
Brand inverter stepless speed regulation, rotational speed accuracy 0.2 rpm
|
|
Work method
|
Two or four tanks operating simultaneously
|
|
Maximum continuous working time
|
72hrs(timing0-9999h)
|
|
Work voltage
|
220V
|
|
Power consumption
|
0.75Kw
|
|
Dimension
|
450×700×550mm
|
