Hot Press Plastic Vacuum Forming Machine 10T Pressure for Pouch Cell

Detail Information

Place of Origin	China	Brand Name	GERUISI
Model Number	GRS-DRY300	Press:	10T
Equipped With:	Micro Short Circuit Testing Function
Highlight	Hot Press vacuum forming machine, Pouch Cell vacuum forming machine, 10T Pressure plastic forming machine

Product Description

Product Description

This device is mainly suitable for thermal flattening and shaping after winding the battery cell, making it easy to enter the shell. The wound cell is placed on the template and shaped by applying pressure and heating to achieve a consistent thickness of the cell, reducing the elasticity of the cell, reducing the short circuit rate of the core, and ensuring consistency in the thickness of the finished cell.

The size specification of the pressure plate is 250 * 200mm (the pressure plate is suitable for wearing battery hot pressing)

Pressure plate material: steel plate

Working pressure of 10 tons

Equipped with micro short circuit testing function

Specification

Technical Parameter

1. 10 ton turbocharged cylinder

2. Upper and lower copper plate heating plates

3. The thickness of the upper and lower working plates is 30MM

4. Panasonic temperature controller

5. Omron time relay adjustable from 0 to 999.9 seconds

6. Yangming solid-state relay
