Main features:
* Heating rolling, thermostat control temperature adjustable, and digital display.
* Can be selected to work with or without heating.
* Roll hardness is high, and the surface is plated with hard chromium, hardness can reach HRC62 and rust prevention.
* Use inclined block to adjust the press gap, good self-locking, high adjustment accuracy.
* High rolling precision, roller cylindricity ≤±2um.
* Vertical design, convenient strip material feed rolling.
* Adopt gear meshing rotation to achieve roller pressing.
* The thickness and speed can be adjusted, and the appearance is exquisite and beautiful.
* Electric rolling, forming automatic, reversible operation.
* Small size, easy operation, flexible and fast use.
Usage method
* Rolling operation: Put the material between the two rollers, press the start button, the motor starts, and drive the gear mesh to drive the two rollers to rotate to achieve roll rolling.
* Roller gap adjustment: The use of inclined block to adjust the press gap, good self-locking, rotate the adjustment hand wheel can adjust the gap, dial indicator value display, intuitive and convenient.
* Temperature adjustment: The green number displayed on the thermostat indicates the current temperature setting value, and the red word indicates the current temperature detection value. Press the "up, down" ammonium key to adjust the set temperature value.
Technical parameter
* Roller diameter: 2-Φ96mm
* Roller hardness: HRC62
* Roller finish: 0.8 or more
* Roller cylindricity ≤±2um.
* Rolling thickness: 0 ~ 2mm adjustable clearance
* Sheet width: 0 ~ 250mm
* Roll placement: vertical placement
* Sheet thickness, speed, heating temperature can be adjusted.
* Rolling temperature: 130℃ adjustable, digital display value
* Operation mode: electric
* Voltage and frequency: AC220V/50Hz
* Power: 2KW
* Feed speed: 0 ~ 40mm/s, speed can be adjusted
* External size: L754mm*W220mm*H325mm
* Equipment weight: 85KG
Standard configuration: a set of Allen wrench, 2 dial gauges, 1 gauge.
