Laser Welding Machine 2000W/4000W for Prismastic Cell, Cylindrical cell or battery pack
- Good beam quality, suitable for fine laser welding
- Various effects required by users can be machined on tiny surfaces. Widely used in automobile, hardware, medical and other linesKarma.
- The minimum focusing spot diameter of the device is about 0.2mm, which is suitable for fine laser welding.
- Stable laser output power, high equipment reliability
- The power fluctuation is less than 3%, ensuring the stable quality of laser welding. Equipment reliability is high, almost no need for maintenance, equipment without consumables, no need to replace xenon lamps, laser rods and other accessories, reduce the cost of shutdown commissioning.
- High efficiency, low energy consumption, saving cost
- The photoelectric conversion efficiency is high, the power loss of the equipment is small, and the power consumption is almost 1/10 of the traditional laser welding equipment.
- The equipment is a new generation of high-power precision laser welding products, using water cooling, compact structure, simple installation, easy maintenance. Easy production line layout or automated integration.
- Independent intellectual property rights of the operating software, easy to operate, powerful
- The special welding software has powerful function and friendly interface. Support PLT, DXF, BMPAI and other file formats
No. | unit | Instructions |
1 | Fiber laser | 2000W; 4000W |
2 | Welding head | Precision double swing welding head |
3 | Industrial computer | Industrial control computer |
4 | Welding control card | Laser welding special control card |
5 | Welding software | Laser welding software |
6 | Control cabinet | Customize the integrated cabinet |
7 | Precision linear modules | Servo motor, Taiwan on silver guide rail |
| NK-FW2000W | NK-FW4000W |
Overall shape | 1200mm×1100mm×1800mm | 1900mm×1200mm×1800mm |
laser | Fiber continuous laser | Fiber continuous laser |
Laser wavelength | 1080nm | 1080nm |
Average output power | 2000W | 4000w |
Power instability | ＜3% | ＜3% |
Modulation frequency | 20KHz | 5KHz |
Beam quality
(BPP) | ＜4.5mm×mrad@100um | ＜4.5mm×mrad@100um |
Three-axis travel (X× Y×Z) | 600mm×400mm×300mm | 600mm×400mm×300mm |
Position repetition accuracy | ±0.05 mm | ±0.05 mm |
Cooling mode | water-cooling | water-cooling |
IPC
| Industrial control main board; Memory: 4G; Solid hard disk: 120G; Liquid crystal display unit | Industrial control main board; Memory: 4G; Solid hard disk: 120G; Liquid crystal display unit |
Welding speed | 1.0M-1.5M/min | 1.0M-1.5M/min |
Welding thickness | 0.5mm-4mm | 0.5mm-6mm |
