Technical parameter
* Active winding, automatic tension control;
* Winding design correction function, good winding uniformity;
* The device comes with independent electrical control system;
* Unwinding and winding two-part separate structure;
* Passive unwinding, tension adjustment;
Equipment technical parameters:
* Tension control :0 ~ 50N
* Winding diameter :250mm
* Winding diameter: 60mm
* Winding accuracy :±0.5mm
* Installation dimensions: uncoil W450mm*D900mm*H615mm, receive W800mm*D900mm*H615mm
* Weight about 200Kg winding, about 237Kg winding
* Power supply voltage single-phase 220VAC±10%(110VAC can be customized), frequency 50Hz/60Hz, * power 500W
* Conveyor mode: continuous operation
* Width of guide roller :350mm
* Mechanical speed :Max.6m/min
