Stacking viscosity
|
The uniformity is better than ± 0.5mm
|
|
Lamination/Stacking size
(including Electrode Tab length)
|
Min. L44mm * W44mm (If it is small, it needs to replace the pressing plate) Max. L200mm * W150mm (the Electrode Tab is on the long
side)
|
|
Laminate/Stacking thickness
|
Max.12mm (if thicker, the adjusting plate needs to be replaced)
|
|
Diaphragm roll diameter
|
Max. 220mm
|
|
Installation dimensions
|
L512mm*W820mm*H580mm
|
|
Weight
|
About 50Kg
|
|
Voltage
|
Voltage single-phase 220VAC ± 10% (110VAC can be customized)
|
|
Frequency
|
50Hz/60Hz
|
|
Power
|
200W
|
|
Compressed air
|
0.4~0.6MPa
|
|
Usage environment
|
Recommended ambient temperature: 25 ± 3 ℃, humidity: 30~90RH, no vibration and electromagnetic interference
|
