Hydraulic Coin Cell Crimping Machine Crimper optional Battery Disassembly

Detail Information

Brand Name	GERUISI	Model Number	GRS-CX120
Machine Type:	Manual Type
Highlight	hydraulic coin cell crimping machine, Battery coin cell crimping machine, hydraulic coin cell crimper

Product Description

It is mainly used for sample ingestion research of battery internal materials. The standard configuration can be used to
disassemble all CR20 series button cell. It has the advantages of small size, convenient operation and accurate disassembly. Different molds can also be configured for sealing, pressing powder and other operations..
Features:
1.Small size, easy to operate, and can be operated in a glove box; Precision mold design ensures accurate and reliable disassembly;
2.Equipped with a safety oil valve, the pressure can be adjusted as needed, and the upper pressure limit can be set to prevent damage caused by excessive pressure due to mis-operation;
3.The CR20 series can be used universally, and the CR2450 and CR1620 can be disassembled only by replacing some mold accessories;

4. Strong steel structure design, stable and safe use; Specially designed hydraulic structure, Saving labor by lifting;
5.The built-in pressure gauge can observe and accurately control the sealing pressure;
6.Beautiful appearance and easy maintenance

Specification

Structure material	Alloy aluminum and high-strength chromium steel, with environmentally friendly electroplating treatment on the surface, never rusting
texture of material	Adopt mold material imported from Japan
Operating force of hand lever	≤5.5kg
Overall dimensions	232mmX165mm×320mm
weight	25kg
Structure material	High strength chrome steel, with environmentally friendly plating and spraying treatment on the surface, never rusting
